A request - Grafting Pics

View previous topic View next topic Go down

A request - Grafting Pics

Post  Kev Bailey on Sun Mar 14, 2010 4:42 pm

I'm booked to do a talk for our club on grafting. I've done some, but would like more pics of different techniques and species that people have tried.

Please post only pics that you wouldn't mind me using. Many thanks

_________________
“It is not the strongest of the species that survives, nor the most intelligent. It is the one that is the most adaptable to change.” - Charles Darwin.

Kev Bailey
Admin


Back to top Go down

A request - Grafting Pics

Post  Guest on Sun Mar 14, 2010 5:01 pm

Only got some approach grafts on pines.

Guest
Guest


Back to top Go down

A request - Grafting Pics

Post  Guest on Sun Mar 14, 2010 5:03 pm

Closer pic of grafted area.

Guest
Guest


Back to top Go down

Re: A request - Grafting Pics

Post  Pavel Slovák on Sun Mar 14, 2010 5:06 pm

Hi Kev.

sample Juniper sabina Wink

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/prikajeni-vetve--juniperus-sabina-2005

Pavel

Pavel Slovák
Member


Back to top Go down

A request - Grafting Pics

Post  Guest on Sun Mar 14, 2010 5:10 pm

Another branch on the same tree. Both branch and trunk were notched out for a snug fit, then screwed together and sealed with cut paste. Performed in August, when the tree was doing its thickening for the year.

Guest
Guest


Back to top Go down

A request - Grafting Pics

Post  Guest on Sun Mar 14, 2010 5:13 pm


Guest
Guest


Back to top Go down

Re: A request - Grafting Pics

Post  Mario Stefano on Sun Mar 14, 2010 5:30 pm

Pavel Slovák wrote:
sample Juniper sabina Wink
Pavel

Oh my God...
affraid
thumbs up

Mario Stefano
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Jay Wilson on Sun Mar 14, 2010 6:07 pm

Two thread grafts on an Acer rubrum. Blue arrows are the exit side.




Jay Wilson
Member


Back to top Go down

Re: A request - Grafting Pics

Post  littleart-fx on Sun Mar 14, 2010 8:02 pm

Hi all!

Marvellous jobs cheers
These pictures teach thumbs up !

Thnx, and grtz. Machiel.

littleart-fx
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Jacos on Sun Mar 14, 2010 8:08 pm

Grafting new roots higher up the stem by means of saplings.
Reason : reverse taper.
Tree is Fagus sylvatica asplenifolia.
Graftings are fagus sylvatica purpurea.

Brgds,
New Bonsai Art



Jacos
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Pavel Slovák on Sun Mar 14, 2010 8:37 pm

Hi Kev.

Still way to get new plants. Certainly frequently used. Wink

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/vzdusne-hrizeni---acer-palmatum

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/acer-palmatum---hrizenec-2005

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/vzdusne-hrizeni-_acer-palmatum-a-prunus-mahaleb_


Pavel

Pavel Slovák
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Kev Bailey on Sun Mar 14, 2010 9:45 pm

Excellent pictures, thanks guys. Please keep them coming. Any unusual techniques, types of graft, species, all are welcomed.

This is collecting from a Scots pine witches broom.


And a year later, the side veneer graft I did, using the collected scion.

_________________
“It is not the strongest of the species that survives, nor the most intelligent. It is the one that is the most adaptable to change.” - Charles Darwin.

Kev Bailey
Admin


Back to top Go down

Re: A request - Grafting Pics

Post  Jose O. Rivera on Mon Mar 15, 2010 1:08 am

Check my web page, you found some grafting with the explain. Look the blog section. http://josorl.webs.com

Jose O. Rivera
Member


Back to top Go down

Re: A request - Grafting Pics

Post  geoff on Wed Mar 17, 2010 5:36 pm

Hi Kev,
Here's Trident Maple root graft I started about 2 yrs ago. The graft was made with a small tree 15 - 20 mm in diameter, a deep groove was put in the main tree and the bark striped off the small tree where they meet. I got the cambium to join as best I could and covered it with cut paste.


Before



After
I've been graduly reducing the grafted tree.
I've another Trident root graft if you need it.

Geoff

geoff
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Pavel Slovák on Wed Mar 17, 2010 6:14 pm

Hi Kev.

Even change the roots of Carpinus betulus. Very Happy Wink

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/habr-2004---nebari--jak-je-vylepsit


Pavel

Pavel Slovák
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Joe Hatfield on Wed Mar 17, 2010 7:05 pm

Pavel Slovák wrote:Hi Kev.

sample Juniper sabina Wink

http://www.bonsaivigi.cz/fotoalbum/tvarovani-a-vyvoj---styling-and-development/prikajeni-vetve--juniperus-sabina-2005

Pavel

This was very interesting and well done.

Joe Hatfield
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Jacos on Wed Mar 17, 2010 7:37 pm

Here a recent picture of the result of grafting new roots
fagus sylvatica purpurea on my fagus sylvatica purpurea.

[url=New Bonsai Art]http://home.base.be/graulusjl/[/url]




Jacos
Member


Back to top Go down

Re: A request - Grafting Pics

Post  Kev Bailey on Wed Mar 02, 2011 9:59 pm

Thanks so much for the pics posted already guys. Very useful.

I'm afraid I dropped the ball on this one, due to my bout of pneumonia last year and was unable to do the talk. It is rescheduled for later this year, so if anyone else has pics they don't mind me using, I'd be grateful. I'm about to ask Peter Keane if I can use his on Pine and Juniper, before anyone suggest his Very Happy

_________________
“It is not the strongest of the species that survives, nor the most intelligent. It is the one that is the most adaptable to change.” - Charles Darwin.

Kev Bailey
Admin


Back to top Go down

Re: A request - Grafting Pics

Post  tim stubbs on Wed Mar 02, 2011 10:07 pm

Mario Stefano wrote:
Pavel Slovák wrote:
sample Juniper sabina Wink
Pavel

Oh my God...
affraid
thumbs up

does that mean you dont approve ?

tim stubbs
Member


Back to top Go down

Re: A request - Grafting Pics

Post  peter keane on Thu Mar 03, 2011 2:19 am

hi Kevin

here's a thread graft to a shohinl korean hornbeam. The graft took in only two seasons.



peter keane
Member


Back to top Go down

Re: A request - Grafting Pics

Post  peter keane on Thu Mar 03, 2011 2:22 am

and this is a "tongued approach graft" of scots to ponderosa pine. I separated the scots from its rootstock after one year. I wish I had left it for another season as the scots is suffering. I'll know if I was too ambitious this year, or, maybe scots to ponderosa doesn't work?




peter keane
Member


Back to top Go down

Re: A request - Grafting Pics

Post  peter keane on Thu Mar 03, 2011 2:56 am

here's another set. this is with the taping of foliage with buddy tape. the scion is a japanese black pine attached to the same tree in another spot. The shoot was removed and grafted to the branch in one day without being "held back" in February 2010. It wasn't until June when I saw that the new candle was growing. I had to tease the tape open since I wrapped the scion with two pieces.




peter keane
Member


Back to top Go down

Re: A request - Grafting Pics

Post  ogi uyehara on Thu Mar 03, 2011 8:09 am

hope this will help
growing[img][/img]

selection of branches


[img][/img]

grafting
[img][/img]

detail



[img][/img][img

ogi uyehara
Member


Back to top Go down

Re: A request - Grafting Pics

Post  ogi uyehara on Thu Mar 03, 2011 8:14 am

By the way, the tree a premna odorata. Premna microphylla is the one I graft that came from Taiwan.

ogi uyehara
Member


Back to top Go down
